European LD 5T 10T Single Girder Warehouse Overhead Crane for Workshop

European LD 5T 10T Single Girder Warehouse Overhead Crane for Workshop

European LD Type Single Girder Warehouse Overhead Crane single girder overhead crane is designed in accordance with European standard with compact structure, small wheel pressure, which carries out effective use of limited plant space, and reduce the cost of plant structure.

10T single girder overhead crane is widely used in machinery manufacturing, metallurgy, ports, railway stations, warehouses and other occasions, providing more efficient logistics solutions, especially for accurate positioning operation.

Product:

Lifting Capacity			T	1t	2t	3t	5t	10t	16t	20t
Span			m	7.5~22.5m					7.5~31.5
Speed	Lifting	MD1 hoist	m/min	8/0.8 (7/0.7)					3.5/0.35
		CD1 hoist		8 (7)					3.5
	Traveling of electric hoist			20					20
	Traveling of crane			20/30					20/30
Wheel diameter				Φ270					Φ370
Width of trail				37~70mm					37~70mm
Operational Model				Remote control; Ground handle					Remote control; Ground handle
Working Duty				A3
Power Supply				Three-phase A.C. 380V, 50Hz					Three-phase A.C. 380V, 50Hz

• Features of European standard bridge crane


1. Computer-designed box beam, the whole length of the web plate is cut by NC with accurate deflection;

2. Low clearance trolley structure with reasonable sized hook, thus it has wide application scope;

3. Arc or flat wheels, anti - friction bearings, honeycomb bumper, anti - derailment device;

4. Three- in-one motor drive, stepless speed control, hardened gear reducer, safety disk brake;

5. Good driving performance, stepless speed regulation, smooth running;

6. Whole shot blasting Sa2.5 level after welding, release of internal stress, so that the main beam structure has best performance;

7. Epoxy zinc-rich paint with oil film thickness 140μm;

• Electric Hoist

1. Lifting motor: Tapered rotor three-phase asynchronous braking motors
2. Reducer: Three-level dead axle helical gear rotating body, Gear and the axle made by alloy steel after heat treatment, high intensity

3. Rope drum: Made of cast iron or seamless steel tube, light weight, transmit the dynamic force by splines.

4. Steel wire rope: It uses GB1102-74(6*37+1) hoist steel wire rope which is durable in use

5. Forge with special steel: thrust ball bearing connect with casing through hook and beam to make the hook operate freely.

• Electrical part of  European standard bridge crane

1. Slip-line power supply;

2. Phase protection, disconnected main power in case of incorrect phase;

3. Independent crane and hoist travelling, also both running at the same time;

4. Trolley/hoist line meets the power requirements and adapts to vibration;

5. Anti-corrosion control handle with protection class IP54

6. Heavy duty aviation plug;

7. Electrical components are installed in the convenient location for maintenance with good protection to avoid accidental contact;

8. Cable is hanging in the cable car, running C-shaped steel, sliding flexibility;

• Safety Protection Devices

1. Locked fall-proof reducer

2. Outdoor hoist with rain-cover

3. Alarm indicator lights

4. Infrared anti-collision

WeiHua Overhead Crane Manufacturers Related Products

	18 Ton Electric Hoist Single Girder Eot Crane        Lifting capacity: 1T - 18T With Hoist and Remote Control
	5 Ton HD Type Single Girder Overhead Crane       Lifting capacity: 1T - 5T HD Type Single Girder

	30-40 T Mobile Rubber Tyre Gantry Crane Lifting capacity: 30t-40t Power Source:380V/50Hz/3P Duty Class: A6-A7
	MH Single Electric Gantry Crane Lifting capacity: 20 Ton Power Source:380V/50Hz/3P Duty Class: A6-A7 Span: 7.5-31.5

 Weihua Gantry Crane and Other Popular Cranes

The products meet the factory, workshop, port, mining, waste disposal, goods scattered, petrochemical, aerospace, military and other industries of universal bridge crane, overhead crane, EOT crane, door crane, universal gantry crane, rubber tyre and rail mounted container gantry crane four link type portal crane, quayside container crane, crane, crane hook, mining grab crane, gantry crane, ship loader, grab bucket ship unloader, stacker reclaimer, dredger, mobile platforms and other types of hydraulic crane technical requirements.

WEIHUA Crane Manufacturer and Supplier founded China’s first crane design R & D team and there are 500 personnel now, developed the anti-swing technology independently and has obtained more than 100 patents. Weihua has been the post-doctoral scientific research workstation of Henan Province for four consecutive 4 years. Weihua has its own independent laboratory and has passed the CNAS certification, it is the only one industrial crane production and testing base appointed by government.

WeiHua own professional engineers and technicians for Quality Control (the Standards are in terms of pre-production, producing process, after-production.)

1. Senior purchasers source parts as electric devices and menchanical parts, then QC inspect the spare parts before entring the warehouse.

2. During producing and assembly, senior QC proceed to inspect.

3. Senior engineers debug and test the machines after customers order and before shipment.

 Further more, as the designated supplier of Jiuquan Satellite Launch Base, Weihua accelerated the launch of Chang'e successfully.

Unique Weihua Crane Services

1. Fast and timely response for any overhead industrial cranes inquiry.

2. Free custom design service for any our sale of industrial cranes

3. Quite competitive price that usually fifth less than the other industrial crane sales manufacturers

4. Anytime to receive your visit to our cheap industrial crane factory.

After-sale service of industrial cranes

1. Offer you high quality industrial hoist and crane, which made by advanced technology and professional industrial cranes engineers.

2. Free industrial cranes for sale operation training until you get it clearly and totally though many ways, such as the internet, face to face, or phone and email.

3. One year free maintenance and lifetime maintenance for your overhead industrial cranes

4. Free test for your industrial cranes on the basis of related standard, and send you the industrial cranes test certification.

5. Free and cheap industrial crane delivery suggestion from our rich sales managers.

 Questions

• 1. How long is WeiHua products warranty?

  We afford 12 months of quality warranty period after customers buy from us.


• 2. What's the warranty content?

  We will provide free onsite service on repairing and replacing malfunctioning or damaged parts which are proved to be our manufacturing quality defects within the warranty period.


• 3. What if is out of warranty period?

• (1) We will provide chargeable onsite service on repairing and replacing malfunctioning or damaged parts after the warranty period.

• (2) We will supply dispensable parts preferentially for a long period.

• (3) We will keep in touch with customers to track and survey of the product.

•


•
