Industrial Supply Muffler Clamp Sizes Stainless Steel Pipe Single Ear Hose Clamps Price

Payment Terms: TT or LC

Ref Price : 0.01-10 USD/PIECE

Supply Capability : 5000000 PIECE

Loading Port : TianJin

Inquire Now Chat Online

Sino-Sources Service Pledge

  • Quality Product Quality Product
  • Purchasing Credit Purchasing
  • Credit Rating Credit Rating
  • Timely Delivery Timely Delivery
  • Order On-line Tracking Order On-line Tracking
  • Credit Services Credit Services

Quick Details

  • Place of Origin：
    Tianjin, China
  • Brand Name：
    Shunfa
  • Usage：
    Pipe Clamp
  • Material：
    Aluminized
  • Structure：
    Adjustable
  • Type：
    Exhaust Clamp
  • Surface Finish：
    Mirror Polished/Brushed/Sandblasting
  • Standard or Nonstandard：
    Standard
  • Port：
    Tianjin


Product Overview

Type  Exhaust Clamp
Brand Name  ZENGBANG
Size

 Customized according to your needs.
Material  SUS304
Application

 Customized according to your needs.
MOQ  5 sets
Port  Ningbo/Shanghai
Warranty  1 years
Surface Finish  Natural/Mirror Reflection/Ceramics/Paint
Features

  • The clamp is made of 14 steps of stainless steel belt rolling reduction, stamping, bending and expansion.

  • The clamp has the characteristics of beautiful surface and durability.

  • The clamp is mainly used for automobile muffler and various pipe connections of different diameters.

  • The clamp is a round tube connection and fastening product.



Features

1.Made of Stainless Steel with Computerized Mandrel-Bent for Strength and Durability

2.Surface Finished with Stainless Steel

3.Each set is tested and dynoed to make sure the fitment and performance meet our goal.

4.Increase Horsepower and Torque

5.Mandrel bent tubing, CAD-rendered, CNC Machined Flanges.

6.Gain More performance Due to More Air Flow

7.Better fuel mileage with improved combustion

8.Professional Installation is Highly Recommended


Steel strip width:5MM   Steel strip thickness:0.5MM

Model Clamping range Ear width Clamping force PCS/box Single
S5065 5.3-6.5 4 1000N 20000 0.820
S5070 5.8-7.0 4 1000N 20000 0.885
S5080 6.8-8.0 4 1000N 20000 0.920
S5087 7.0-8.7 5.5 1000N 20000 1.032
S5090 7.3-9.0 5.5 1000N 20000 0.980
S5095 7.8-9.5 5.5 1000N 20000 1.098
S5100 8.3-10.0 5.5 1000N 10000 1.030
S5105 8.8-10.5 5.5 1000N 10000 1.080
S5109 9.2-10.9 5.5 1000N 10000 1.100
S5113 9.6-11.3 5.5 1000N 10000 1.200
S5118 10.1-11.8 5.5 2100N 10000 1.230



Steel strip width:7MM   Steel strip thickness:0.6MM

Model Clamping range Ear width Clamping force PCS/box Single
S7119 9.4-11.9 8 2100N 5000 2.39
S7123 9.6-12.3 8 2100N 5000 2.41
S7128 10.3-12.8 8 2100N 5000 2.44
S7133 10.8-13.3 8 2100N 5000 2.47
S7138 11.3-13.8 8 2100N 5000 2.5
S7140 11.5-14.0 8 2100N 5000 2.52
S7142 11.7-14.2 8 2100N 5000 2.53
S7145 12.0-14.5 8 2100N 5000 2.6
S7148 12.3-14.8 8 2100N 5000 2.64
S7153 12.8-15.3 8 2100N 5000 2.7
S7157 13.2-15.7 8 2100N 5000 2.71
S7160 13.5-16.0 8 2100N 5000 2.8
S7162 13.7-16.2 8 2100N 5000 2.83
S7166 14.1-16.6 8 2100N 5000 3.18
S7168 14.3-16.8 8 2100N 5000 3.2
S7170 14.5-17.0 8 2100N 5000 3.08
S7175 15.0-17.5 8 2100N 5000 3.2
S7178 14.6-17.8 10 2400N 5000 3.2
S7180 14.8-18.0 10 2400N 5000 3.2
S7185 15.3-18.5 10 2400N 5000 3.2
S7192 16.0-19.2 10 2400N 5000 3.33
S7198 16.6-19.8 10 2400N 5000 3.43
S7210 17.8-21.0 10 2400N 5000 3.6
S7226 19.4-22.6 10 2400N 5000 3.68
S7235 20.3-23.5 10 2400N 5000 3.7
S7241 20.9-24.1 10 2400N 5000 3.79
S7256 22.4-25.6 10 2400N 5000 4.03
S7271 23.9-27.1 10 2400N 5000 4.27
S7288 25.4-28.6 10 2400N 5000 4
S7301 26.9-30.1 10 2400N 5000 4.448
S7306 27.6-30.8 10 2400N 2000 4.56
S7316 28.4-31.6 10 2400N 2000 4.63
S7331 29.9-33.1 10 2400N 2000 4.73
S7346 31.4-34.6 10 2400N 2000 5.01
S7361 32.9-36.1 10 2400N 2000 4.94
S7376 34.4-37.6 10 2400N 2000 5.01
S7381 34.9-38.1 10 2400N 2000 5.07
S7396 36.4-39.6 10 2400N 2000 5.14
S7410 37.8-41.0 10 2400N 1000 5.35
S7426 39.3-42.5 10 2400N 1000 5.58
S7440 40.8-44.0 10 2400N 1000 5.81
S7455 42.3-45.5 10 2400N 1000 6.01
S7470 43.8-47.0 10 2400N 1000 6.235
S7485 45.3-48.5 10 2400N 1000 6.37
S7500 46.8-50.0 10 2400N 1000 6.51
S7515 48.3-51.5 10 2400N 1000 6.675
S7530 49.8-53.0 10 2400N 1000 6.84
S7545 51.3-54.5 10 2400N 1000 7.01
S7560 52.8-55.0 10 2400N 1000 7.17
S7575 54.3-57.5 10 2400N 1000 7.335
S7590 55.8-59.0 10 2400N 1000 7.5
S7606 57.3-60.5 10 2400N 1000 7.665
S7092 88.8-92.0 10 2400N 500 11.14
