T-Bolt Hose Clamps（SAE）

Payment Terms: TT or LC

Ref Price : 32-35 USD/PIECE

Supply Capability : 80000 PIECE

Loading Port : TianJin

Inquire Now Chat Online

Sino-Sources Service Pledge

  • Quality Product Quality Product
  • Purchasing Credit Purchasing
  • Credit Rating Credit Rating
  • Timely Delivery Timely Delivery
  • Order On-line Tracking Order On-line Tracking
  • Credit Services Credit Services

Quick Details

  • Model Number：
    CS52SV-200-X
  • Usage：
    Heavy Duty, hose clamps
  • Material：
    Stainless Steel
  • Structure：
    T Clamp
  • Size：
    1.25~7.5 inches
  • Band Width：
    19mm
  • Application：
    Heavy-Duty

T-Bolt Hose Clamps（SAE）

TX19Bb Series：Channel bridge，Screw：T-bolts head carbon steel，Nut：hex lockout。band and bridge plate material 300 stainless steel。

TX19Q Series：Channel bridge，Screw：T-bolts head stainless steel，Nut：hex lockout。band and bridge plate material 300 stainless steel。

TX19B Series：Floating Channel bridge，Screw：T-bolts head carbon steel，Nut：hex lockout。band and bridge plate material 300 stainless steel。

Product specifications And details

型号
Model		 规格
Size		 紧固范围
Range		 带宽
Width		 带厚
Thickness		 螺杆
Screw		 每箱数量
pcs/caton		 外箱尺寸
Carton's Size cm
- - 32 ~ 37 19mm±0.1 0.6~1
300 37*28*21
- - 35 ~ 40 19mm±0.1 0.6~1
250 37*28*21
- - 38 ~ 43 19mm±0.1 0.6~1
250 37*28*21
- - 41 ~ 46 19mm±0.1 0.6~1
- -
28 28 44 ~ 52 19mm±0.1 0.6~1
- -
30 30 44 ~ 52 19mm±0.1 0.6~1
- -
30 30 46 ~ 54 19mm±0.1 0.6~1
- -
34 34 50 ~ 58 19mm±0.1 0.6~1
- -
40 40 54 ~ 62 19mm±0.1 0.6~1
200 38.5*38*23
46 46 59 ~ 67 19mm±0.1 0.6~1
200 38.5x38x23
52 52 64 ~ 72 19mm±0.1 0.6~1
200 38.5x38x26.5
58 58 69 ~ 77 19mm±0.1 0.6~1
200 58x38x19
64 64 73 ~ 81 19mm±0.1 0.6~1
200 58*38*19
70 70 78 ~ 86 19mm±0.1 0.6~1
200 38.5x38x29.5
76 76 83 ~ 91 19mm±0.1 0.6~1
200 58*38*23
82 82 88 ~ 96 19mm±0.1 0.6~1
200 58*38*23
88 88 92 ~ 100 19mm±0.1 0.6~1
150 58*38*19
94 94 97 ~ 105 19mm±0.1 0.6~1
150 58*38*21
100 100 102 ~ 110 19mm±0.1 0.6~1
150 58*38*21
108 108 108 ~ 116 19mm±0.1 0.6~1
150 58*38*21
116 116 114 ~ 122 19mm±0.1 0.6~1
- -
124 124 121 ~ 129 19mm±0.1 0.6~1
- -
132 132 127 ~ 135 19mm±0.1 0.6~1
- -
140 140 134 ~ 142 19mm±0.1 0.6~1
150 58*38*29.5
148 148 140 ~ 148 19mm±0.1 0.6~1
150 58*38*29.5
156 156 146 ~ 154 19mm±0.1 0.6~1
- -
164 164 153 ~ 161 19mm±0.1 0.6~1
- -
172 172 159 ~ 167 19mm±0.1 0.6~1
- -
180 180 165 ~ 173 19mm±0.1 0.6~1
- -
188 188 172 ~ 180 19mm±0.1 0.6~1
- -
196 196 178 ~ 186 19mm±0.1 0.6~1
- -
204 204 184 ~ 192 19mm±0.1 0.6~1
- -
212 212 191 ~ 199 19mm±0.1 0.6~1
- -
220 220 197 ~ 205 19mm±0.1 0.6~1
- -
228 228 204 ~ 212 19mm±0.1 0.6~1
- -
236 236 210 ~ 218 19mm±0.1 0.6~1
- -
244 244 216 ~ 224 19mm±0.1 0.6~1
- -
252 252 223 ~ 231 19mm±0.1 0.6~1
- -
260 260 229 ~ 237 19mm±0.1 0.6~1
- -
268 268 235 ~ 243 19mm±0.1 0.6~1


276 276 242 ~ 250 19mm±0.1 0.6~1


284 284 248 ~ 256 19mm±0.1 0.6~1


292 292 254 ~ 262 19mm±0.1 0.6~1


300 300 261 ~ 269 19mm±0.1 0.6~1


308 308 267 ~ 275 19mm±0.1 0.6~1


316 316 273 ~ 281 19mm±0.1 0.6~1


324 324 280 ~ 288 19mm±0.1 0.6~1
100 58*38*29.5
332 332 286 ~ 294 19mm±0.1 0.6~1


340 340 292 ~ 300 19mm±0.1 0.6~1









Tianjin Shunfa Universal Clamp Co.,Ltd was founded in 2002. The manufacture covers an area of 340,000 square meters, with a construction area of 250,000 square meters and 1000 employees.The company has great experience in the clamp production industry. Years of technology and quality assurance have enabled us to have a broad customer base in the globle market.

The company's main products are: stainless steel clamp standard parts and non-standard, stainless steel hose clamps, rubber and other products, and exported to Asia, Africa, Europe, the Middle East, the Amerias, and many parts of the world.

We have a first-class technology research and development demand that we provide our customers with the best quality products and services.We sincerely hope to establish long-term trade links with customers from all over the world. If you know more about our company, please contact :shunfa@sino-sources.com


Shunfa Universal Clamp main produce various specifications hose clamp,commit to provide best quality hose clamps products for overseas users.
