Payment Terms: TT or LC
Ref Price : 20-220 USD/METERS
Product Description:
Item |
Rock Wool |
Density |
50-200 kg/m3 |
Average fiber diameter |
≤ 7.0 um |
Thickness |
30-120mm |
Length * width |
(500-1200)*(50-150)mm |
Highest Usage Temperature |
600℃ |
Heat Conduct Coefficient |
0.043-0.032w/mk |
Hydrophobic |
>98.5 |
Incombustibility |
Qualified Grade A |
Color |
Yellow ,White ,Pink |
Port of loading |
Tianjin,China main port |
Advantages and features:
1.Excellent thermal insulation --very low thermal conductivity coefficients.
2.Excellent acoustic insulation --can reduce noise and sound transmitting.
3.Moisture resistant,fire resistant.
4.Good strength to resist defomation.
5.Antisepsis,aging resistance,anticorrosion,ensuring a heath environment.
6.Stable physical and chemical properties,durable.
7.Easy for construction;cutting at will.
Density (kg/m3) | 60 | 80 | 100 | 140 | |||
Thickness (mm) | 50-120 | 50-120 | 40-100 | 30-100 | |||
Length * width (mm) | (500-1200)*(50-150)mm | ||||||
Service temperature(°C) | ≤600 °C | ||||||
Thermal conductivity: W/m.K(kcal/m.h.°C) | |||||||
100 °C | 0.043~0.037 | 0.042~0.036 | 0.041~0.035 | 0.040~0.034 | |||
200 °C | 0.061~0.052 | 0.057~0.049 | 0.057~0.049 | 0.054~0.046 | |||
300 °C | 0.086~0.075 | 0.077~0.066 | 0.073~0.063 | 0.070~0.060 | |||
400 °C | 0.123~0.106 | 0.099~0.085 | 0.095~0.082 | 0.089~0.077 |
More technology data:
Fiber Diameter | ≤ 6.5 um | |||||
Shot Content | ≤ 10.0% ( particle diameter≥ 0.25mm) | |||||
Density Tolerance | ±5% | |||||
Water repellence | ≥ 98 | |||||
Water absorption | ≤ 2 | |||||
Moisture Aborption | ≤ 0.5% | |||||
Combusion Property | Non-combustible (A class) | |||||
Organic material | ≤ 4.0% | |||||
PH | Neutral, 7.0 ~ 8.0 | |||||
Tensile strength | 220 kPa | |||||
Compression strength | 105 kPa |
WanMaiDe estabished in 2001, a leading manufacturer and exporter of Glass Wool, Rock Wool, Rubber Foam, Foam Glass,Extrude Polystyrene/XPS, Phenolic foam board insulation in China. After more than 20 years' development, we totally have 10 producing lines for glass wool insulation,5 producing lines for rock wool insulation and more than 30 producing lines for rubber foam insulation.
We had mad OEM production for WANMAIDE which are popular due to the high quality and competitive price all over the world.
