Worm Drive Hose Clamps-Perforation

Please enter your email.

cancel

Tianjin Shunfa Universal Clamp Manufacturing Co Ltd

lv1 shield

lv1 shield
< >

Worm Drive Hose Clamps-Perforation

Payment Terms: TT or LC

Ref Price : 2-4 USD/PIECE

Supply Capability : 15000 PIECE

Loading Port : TianJin

Inquire Now Chat Online

Sino-Sources Service Pledge

  • Quality Product Quality Product
  • Purchasing Credit Purchasing
  • Credit Rating Credit Rating
  • Timely Delivery Timely Delivery
  • Order On-line Tracking Order On-line Tracking
  • Credit Services Credit Services

Quick Details

  • Material：
    Stainless Steel, Stainless steel 201/304/316; W4
  • Brand Name：
    Shunfa
  • Usage：
    Pipe Clamp
  • Standard or Nonstard：
    Standard
  • Structure：
    Swivel Clamp, Perforated hose clamp
  • Product name：
    Worm drive butterfly hose clamp with thumb screw
  • Product Type：
    American type hose clamp
  • Adjust range：
    8mm to 400mm or according to your requirement
  • Bandwidth：
    8mm or 12mm or 12.7mm
  • Bandwidth Thickness：
    0.6mm
  • Surface treatment：
    Blacking, polishing, zinc plating
  • Application：
    Automobile, Aviation, Pipe Connection

Product Description

-----------------------------------------------------------------------------------------------------------------------------

Product Data

Item Name

Worm drive butterfly hose clamp with thumb screw

Material

SS201/304/316 or Galvanized steel

Size

6mm to 400mm and customized

Bandwidth

8mm / 12mm / 12.7mm

Application

Pipe connection

Note:

W1: Band material is Galvanized steel; Housing materil is Galvanized steel; Screw material is Galvanized steel;

W2: Band material is SS201 or SS304; Housing materil is Galvanized steel; Screw material is Galvanized steel;

W4: Band material is SS201 or SS304; Housing materil is SS201 or SS304; Screw material is SS201 or SS304.

Products Show

Product specification

------------------------------------------------------------------------------------------------------------------------------



   ITEM

       SPECIFICATION(mm)

BANDWIDTH

MATERIAL

   1

      6 - 12

8mm

SS201/304/316

   2

     10 - 16

8mm

SS201/304/316

   3

     13 - 19

8mm

SS201/304/316

   4

     16 - 25

8mm

SS201/304/316

   5

     19 - 29

8mm

SS201/304/316

   6

     14 - 27

12mm/12.7mm

SS201/304/316

   7

     18 - 32

12mm/12.7mm

SS201/304/316

   8

    21 - 38

12mm/12.7mm

SS201/304/316

   9

    21 - 44

12mm/12.7mm

SS201/304/316

  10

    27 - 55

12mm/12.7mm

SS201/304/316

  11

    33 - 57

12mm/12.7mm

SS201/304/316

  12

    40 - 63

12mm/12.7mm

SS201/304/316

  13

    46 - 70

12mm/12.7mm

SS201/304/316

  14

    52 - 76

12mm/12.7mm

SS201/304/316

  15

    59 - 82

12mm/12.7mm

SS201/304/316

  16

    65 - 89

12mm/12.7mm

SS201/304/316

  17

    72 - 95

12mm/12.7mm

SS201/304/316

  18

    78 - 101

12mm/12.7mm

SS201/304/316

  19

    84 - 108

12mm/12.7mm

SS201/304/316

  20

    91 - 114

12mm/12.7mm

SS201/304/316

  21

   105 - 127

12mm/12.7mm

SS201/304/316

  22

   118 - 140

12mm/12.7mm

SS201/304/316

  23

   130 - 152

12mm/12.7mm

SS201/304/316

  24

   141 - 165

12mm/12.7mm

SS201/304/316

  25

   155 - 178

12mm/12.7mm

SS201/304/316

  26

   175 - 197

12mm/12.7mm

SS201/304/316

  27

   194 - 216

12mm/12.7mm

SS201/304/316

  28

   213 - 235

12mm/12.7mm

SS201/304/316

  29

   232 - 254

12mm/12.7mm

SS201/304/316

  30

   251 - 273

12mm/12.7mm

SS201/304/316

  31

   270 - 292

12mm/12.7mm

SS201/304/316

  32

   289 - 311

12mm/12.7mm

SS201/304/316

Our Company


Yancheng Xinrong Electronic Technology Co.,Ltd have been engaged in design and manufacturing of industrial heating system, Our company have advanced production lines and testing equipment, who supply clients high quality goods, as well as professional R&D department and service team, who provide customers best heating solutions. Our products have been exported to Europe, America, Asia, Mid East etc. more than 200 countries. We supply different heating element, heating equipment, and temperature measurer.


Adhering to "Quality Best, Customer First and Honesty" business philosophy, the company and domestic and foreign partner make progress together to create a better future.

Our Service

Pre-Sales Service

* Technical solutions & support.
* Sample testing support.
* View our Factory.

After-Sales Service

* Training how to instal the products, training how to use the products
* Service will be always online.

Packing & Delivery

Packing

Size

40 (L) * 30 (W) * 30 (D)

Weight

20KGS

Packaging Details

The normal package is carton(Size: L*W*H). If export to european countries,the wooden box will be fumigated.We will use pe film for packing or pack it according to customers special request.
